Turvec Cubic Mesh Bike Store - Enclosed

SKU
VEC140
From: £8,196.00
£6,830.00

A secure, modular mesh cycle store designed for controlled access and long‑term bike parking. The Turvec Cubic Enclosed Mesh Bike Store provides a robust steel structure with full perimeter enclosure for enhanced security.

Customisable Options:

Product Details:

The Turvec Cubic Enclosed Mesh Bike Store is a purpose‑designed solution for sites that require secure, defined cycle parking with controlled entry.

Constructed using Turvec’s modular Cubic steel framework, the bike store features mesh cladding to all elevations, creating a fully enclosed compound that combines visibility, airflow and security. Lockable gates restrict access to authorised users, making the enclosure suitable for workplaces, residential developments, transport hubs, education sites and public sector environments.

The galvanised steel structure is designed for durability in exposed conditions, while the modular system allows the store to be configured to suit a wide range of capacities and layouts. The Cubic Enclosed Mesh Bike Store can accommodate both single‑tier and two‑tier cycle racks and can be expanded in the future by adding additional modules.

Manufactured to EN 1090 standards and CE marked, the Turvec Cubic Enclosed Mesh Bike Store meets structural compliance requirements for commercial projects. A range of optional finishes and enhancements, including powder coating, green sedum roofs, lighting and access control, allow the enclosure to be tailored to site‑specific needs.

What level of security does the enclosed mesh bike store provide?

The fully enclosed mesh design with lockable gates provides controlled access while maintaining visibility. Security specification, gate arrangement and locking methods can be tailored to site requirements.



How does this differ from the open fronted mesh Cubic?

The enclosed version includes mesh panels and secure gates on all sides, creating a contained cycle compound rather than an open‑access shelter.



Can the store be extended if more bike parking is required?

Yes. The Cubic system is modular, allowing additional bays to be added as demand increases.



Can the enclosure house two‑tier cycle racks?

Yes. Increased‑height Cubic modules are available to accommodate two‑tier cycle parking systems.



Are green roofs available?

Yes. Sedum green roofs can be specified, along with enhanced roof load options where biodiversity or planning requirements apply.

Dimensions & Specifications

The Turvec Cubic Enclosed Mesh Bike Store is based on a modular bay system, enabling flexible layouts driven by capacity and circulation requirements.

Standard module dimensions:

  • Standard module height: 2400mm
  • Two‑tier module height: 3000mm
  • Width per double‑sided module: 6000mm
  • Width per single‑sided module: 4040mm
  • Depth per module: 2210mm
  • Green sedum roof allowance: +100mm overall height

Key specifications:

  • Hot dip galvanised steel structural frame
  • Steel mesh cladding to all elevations
  • Lockable access gates (configuration dependent)
  • Powder‑coated steel roof sheets as standard
  • EN 1090 CE marked construction
  • Integrated rainwater drainage through supporting columns
  • Suitable for surface‑mounted or root‑fixed installation
  • Compatible with single‑tier and two‑tier cycle racks

Final dimensions are determined by internal rack selection and access layout.
